Option Actions
Fail Continue to step 5
5. Reassemble bottom connector subassembly onto the golden sample kit and perform a vacuum leak
test.
6. Perform one of the following actions:
Option Actions
Pass Bottom connector subassembly can be reused.
Fail Scrap the bottom connector subassembly.
7. Proceed with Performing Front Housing Kit Troubleshooting on page 126.
5.11.3.3
Performing Front Housing Kit Troubleshooting
Procedure:
1. Replace the front housing kit, and reassemble the radio.
NOTE: Ensure that the main O-ring, battery connector seal, and SIM card door seal are not
pinched during assembly.
2. Perform the leak test following the steps from Performing Vacuum Leak Test on page 121 or
Performing Hand Pump Vacuum Leak Test on page 123.
3. Perform one of the following actions:
Option Actions
Pass Troubleshooting ends here.
Fail Continue to step 4.
4. Reassemble the front housing kit on to the golden sample kit, and perform the vacuum leak test again.
5. Perform one of the following actions:
Option Actions
Pass Front housing kit is good for reuse.
Fail Scrap the front housing kit.
6. Proceed to Performing Miscellaneous Troubleshooting on page 126
5.11.3.4
Performing Miscellaneous Troubleshooting
Procedure:
1. Reassemble the whole radio.
Leakage may be due to improper assembly.
2. Repeat Performing Leak Area Troubleshooting on page 125 with a second golden sample set.
68015000841-EL
Chapter 5: Maintenance
126
To Next Page
