Test Name Test Setup Radio Setup Test Conditions Limits
30.5–34.5 dBm
(Class 3L)
32.5–36.5 dBm
(Class 3)
RF Gen Level
Burst Power
N/A –90 dBm 28–32 dBm
(Class 4)
30.5–34.5 dBm
(Class 3L)
32.5–36.5 dBm
(Class 3)
Timing Error N/A N/A ±0.25 Symbols
Vector Error N/A N/A Max 10% RMS,
30% Peak
Frequency Error N/A N/A ±100 Hz
Table 23: Test Setups for 806–870 MHz Radio Models
The following table summarizes the required test setup for 806–870 MHz radio models.
Test Name Test Setup Radio Setup Test Conditions Limits
Base Station Reg-
istration
Control Channel 851.8125 MHz 2072 TETRA 800MS
Traffic Channel 851.8125 MHz 2072 TETRA 800MS
Time Slot N/A 3 N/A
Country Code N/A 234 N/A
Network Code N/A 2392 N/A
Base Color N/A 1 N/A
Location Area N/A 22 N/A
Min Rx Level N/A N/A –110 dBm
Max Tx Level N/A N/A 30 dBm (Class 4)
32.5 dBm (Class
3L)
Access Parameter N/A –53 dBm N/A
Mobile Power 30 dBm (Class 4) N/A N/A
32.5 dBm (Class
3L)
Burst Type N/A Normal N/A
Transmitter Burst
Power
RF Gen Level
Burst Power
N/A –90 dBm 28–32 dBm
(Class 4)
30.5–34.5 dBm
(Class 3L)
Timing Error N/A N/A ±0.25 Symbols
68015000841-EL
Chapter 4: Test Setup and Testing
44
