Part Number Description
(Replacement of 85012056001 once inventory depletes.)
85012031001 Whip 110 mm (380–430 MHz)
85012069001 Stubby 36.6 mm (806–870 MHz)
85012070001 Whip 70 mm (806–870 MHz)
Table 29: Programming Cable
Part Number Description
PMKN4127_ Bottom Connector Serial Data Cable
PMKN4129_ TETRA USB Data Cable
Table 30: Miscellaneous
Part Number Description
PMHN4178_ Slim Connector Dust Cover Assembly
PMHN4210_ Bottom Connector Dust Cover
PMLN6285_ 5-Color Rings for Antenna (Blue)
PMLN6286_ 5-Color Rings for Antenna (Pearl White)
PMLN6287_ 5-Color Rings for Antenna (Neon Green)
PMLN6288_ 5-Color Rings for Antenna (Neon Yellow)
PMLN6289_ 5-Color Rings for Antenna (Neon Red)
PMUE4100_
(AES128)
Encryption IC board
PMUE4101_
(AES256)
Encryption IC board
36012016002 Volume knob
36012017002 Frequency knob
5.4
General Repair Procedures and Techniques
Environmentally Preferred Products (EPP) were developed and assembled using environmentally preferred
components and solder assembly techniques. These are in compliant with the European Union's Restriction
of Hazardous Substances (ROHS 2) Directive 2011/65/EU and Waste Electrical and Electronic Equipment
(WEEE) Directive 2012/19/EU. To maintain product compliance and reliability, use only the Motorola
Solutions specified parts in this manual.
For the identification of lead (Pb) free assemblies, all EPP products carry the EPP Marking on the Printed
Circuit Board (PCB). The following images show examples of the EPP Marking, adhering to the JEDEC
Standard No. 97. This marking provides information to those performing assembly, servicing, and recycling
operation on this product. The EPP Marking takes the form of a label or marking on the PCB.
68015000841-EL
Chapter 5: Maintenance
70
