No. Part/Kit Number Description Remark
2 75012148002 LCD module conductive pad Serviceable.
3 72012010002 LCD module
4 0386434Z02 Speaker retainer screw
5 – Seal, earpiece Not serviceable. Included
in item #19.
6 42012045001 Speaker retainer Serviceable.
7 50012013002 Speaker assembly
8 0386434Z03 Keypad bezel screw M1.4
9 – Speaker mesh Not serviceable. Included
in item #19.
10 Full keypad flex assembly Not serviceable. Included
in item #20.
11 Mylar dome, main keypad
12 Membrane, bottom mic
13 75012097001
2
Main keypad (Hebrew) Serviceable.
75012097002
3
Main keypad (Chinese)
75012097003
3
Main keypad (Bopomofo)
75012097004
2
Main keypad (Cyrillic)
75012097005
2
Main keypad (Arabic)
75012097006
3
Main keypad (Korea)
75012097007
2
Main keypad (Roman)
75012097008
3
Main keypad (Japanese)
14 13012019001 Keypad bezel
15 75012099001 LCD module back pad
16 – Bluetooth antenna assembly Not serviceable. Included
in item #19.
4
17 UC+ earpiece flex assembly
18 33012020001 UC Escutcheon Serviceable. Included in
item #19.
19 0104042J07
5
Front housing assembly Not serviceable. Compris-
es of item #5, 9, 16, 17,
and 18.
0104064J81 Front housing assembly, MTP3550
0104065J27
6
Front housing assembly without Bluetooth
0104065J29
6
Front housing assembly with Bluetooth
2
Available in EMEA region.
3
Available in APAC region.
4
Bluetooth is not applicable for MTP3150.
5
MTP3150 and MTP3250 Version A. This radio model displays above the user
interface screen.
6
MTP3150 and MTP3250 Version B. This radio model displays
above the user
interface screen.
68015000841-EL
Chapter 5: Maintenance
79
