Motorola AP-6511 - Page 193

Wireless Configuration
6-59
Figure 6-26 Smart RF Channel and Power screen
8. Refer to the Power Settings to define Smart RF recovery settings for either the selected 5.0 GHz
(802.11a) or 2.4 GHz (802.11bg) radio.
NOTE: The Power Settings and Channel Settings parameters are only enabled when
Custom is selected as the Sensitivity setting from the Basic Configuration screen.
5.0 GHz Minimum
Power
Use the spinner control to select a 1 - 20 dBm minimum power level for
Smart RF to assign to a radio in the 5 GHz band. 1 dBm is the default
setting.
5.0 GHz Maximum
Power
Use the spinner control to select a 1 - 20 dBm maximum power level Smart
RF can assign a radio in the 5 GHz band. 17 dBm is the default setting.
2.4 GHz Minimum
Power
Use the spinner control to select a 1 - 20 dBm minimum power level Smart
RF can assign a radio in the 2.4 GHz band. 1 dBm is the default setting.
2.4 GHz Maximum
Power
Use the spinner control to select a 1 - 20 dBm maximum power level Smart
RF can assign a radio in the 2.4 GHz band. 17 dBm is the default setting.
