A - 2 MC9190-G User Guide
Application
Development
PSDK and EMDK available through Motorola Support Central Web site.
Data Capture
Options
SE960: 1D standard range scan engine
SE1524-ER: 1D extended range scan engine reads up to 45 ft./13.72 m away
SE4600: Extended range omnidirectional 1D/2D imaging engine reads 1D and 2D symbols as
close as 8 in./20.32 cm and as far as 30 ft./9.14 m
SE4500-SR: Omnidirectional 1D/2D imaging engine reads 1D and 2D symbols
SE4500-DL: 1D/2D DL imaging engine reads all 1D and 2D codes as well as the PDF codes
found on driver’s licenses and other identification documents
SE4500-HD: 1D/2D DPM imaging engine reads a wide variety of DPM marks on metal, plastic
and glass surfaces, including: dot peening, laser etching, molding, stamping or casting.
User Environment
Operating
Temperature
-4°F to 122°F (-20°C to 50°C)
Storage
Temperature
-40°F to 158°F (-40°C to 70°C)
Battery Charging
Temperature
32 °F to 104 °F (0 °C to +40 °C)
Humidity 5% to 95% non condensing
Drop
Specification
Multiple drops to concrete: 6 ft./1.8 m across the operating temperature range; meets and
exceeds MIL-STD 810G
Tumble 2,000 one-meter tumbles at room temperature (4,000 hits) per IEC Tumble Specification
Environmental
Sealing
IP64 (electronic enclosure, display and keypad) per IEC Sealing Specification
ESD +/-15kVdc air discharge
+/-8kVdc direct discharge
+/-8kVdc indirect discharge
Table A-1
Technical Specifications (Continued)
Item Description
