Keypads C - 17
VT Emulator Keypad
The VT emulator keypad contains a Power button, application keys, scroll keys and a function key. The keypad is
color-coded to indicate the alternate function key (blue) values. Note that keypad functions can be changed by an
application so the MC9190-G’s keypad may not function exactly as described. See Table C-6 on page C-18 for key
and button descriptions and Table C-7 on page C-20 for the keypad’s special functions.
Figure C-6
VT Emulator Keypad
NOTE The VT emulator configuration is only used when the MC9190-G is running the VT emulation software. When
the MC9190-G is not running the VT emulation software, the VT keypad functions are the same as a 53-key
keypad.
