3 - 6 MC9190-G User Guide
1. Tap Start > Programs > Samples.
2. Double-tap Imager icon.
To exit the application, tap File > Exit.
Using the RS507 Hands-free Imager
An RS507 Hands-free Imager can be used with the MC9190-G to capture bar code data.
To set up the RS507:
1. Tap Start > Programs > BTScannerCtlPanel icon.
2. If required, select the BT Scanner checkbox and then select the appropriate Com port from the drop-down list.
3. Tap Save and Exit.
4. Tap Start > Programs > BT Information.
5. Tap Generate Local BD Address Barcode. A bar code displays.
6. Point the RS507 at the bar code. The RS507 reads the bar code and begins pairing with the MC9190-G.
Refer to the RS507 Hands-free Imager Product Reference Guide for more information.
NOTE Only one RS507 can be paired with the MC9190-G at a time.
NOTE If the MC9190-G with Windows CE is set to VGA mode the RS507 cannot read the bar code due to the
smaller bar code size. Refer to the RS507 Hands-free Imager Product Reference Guide for instruction for
printing a pairing bar code.
