Motorola MC9190-G User Manual

Chapter 3 Data Capture
The MC9190-G has integrated laser scanners or imagers that collect data by scanning bar codes.
• Standard Range Laser
• Long Range Laser
• Standard Range Imager (standard range, high density (DPM) or driver license)
• Long Range Imager.
Scan LED Indicators
The red/green Scan LED Indicators (located in the Indicator LED Bar) indicates the scan status. For the location of
the Scan LED Indicators see, Figure 1-1 on page 1-2.
LED Status Indication
Off Not scanning.
Solid Red Laser enabled, scanning in process.
Solid Green Successful decode.
Laser Scanning
To read a bar code, a scan-enabled application is required. The MC9190-G with Windows Mobile contains the
DataWedge application and MC9190-G with Windows CE contains the DataWedge and ScanSamp2 Example
applications that allows the user to enable the scanner to decode bar code data and display the bar code content.
See DataWedge on page 3-5 for information on launching DataWedge and ScanSamp2 Example on page 3-5 for
launching ScanSamp2 Example.
1. Launch a scanning application or a sample scanning application (DataWedge or ScanSamp2 Example).
2. Point the exit window on the top of the MC9190-G at a bar code.
Table 3-1 Scan LED Indicators
