1 - 4 MC9190-G User Guide
Cradles: The MC9190-G slips into the cradles for charging the battery in the MC9190-G (and spare batteries,
where applicable). For detailed cradle setup and charging procedures refer to the MC9190 Integrator Guide.
Single Slot Serial/USB Cradle.
Four Slot Ethernet Cradle
Four Slot Charge Only Cradle.
Accessories: The MC9190-G snap-on accessories provide charging capability, when used with one of the
accessory charging cables. For detailed snap-on setup and charging procedures refer to the MC9190
Integrator Guide.
CAM
MSR.
Chargers: The MC9190-G spare battery charging accessories are used to charge batteries that are removed
from the MC9190-G. For detailed spare battery charging accessories setup and charging procedures refer to
the MC9190 Integrator Guide.
Single Slot Serial/USB Cradle
Four Slot Spare Battery Charger
Universal Battery Charger (UBC) Adapter.
To charge the main battery:
1. Ensure the accessory used to charge the main battery is connected to the appropriate power source.
2. Insert the MC9190-G into a cradle or attach the appropriate snap-on module.
3. The MC9190-G starts to charge automatically. The amber charge LED, in the Indicator LED Bar, lights to
indicate the charge status. See Table 1-1 for charging indications.
The main battery usually fully charges in less than four hours.
Charging Spare Batteries
Use the following three accessories to charge spare batteries:
Single Slot Serial/USB Cradle
NOTE To achieve the best battery life in MC9190-Gs with multiple radios, turn off the radios that are not being used.
See Turning Off the Radios on page 1-8 for more information.
Table 1-1
MC9190-G LED Charge Indicators
LED Indication
Off MC9190-G not in cradle or connected to a CAM or MSR. MC9190-G not placed correctly.
Charger is not powered.
Fast Blinking Amber Error in charging; check placement of the MC9190-G.
Slow Blinking Amber MC9190-G is charging.
Solid Amber Charging complete.
Note: When the battery is initially inserted in the MC9190-G, the amber LED flashes once if
the battery power is low or the battery is not fully inserted.
