Motorola MC9190-G - Status Bar Icons

Operating the MC9190-G 2 - 9
Figure 2-8 Status Bar Icons
Tap the Status Bar to display an Icon bar. Tap an icon to get additional notification or status information.
Table 2-5 Status Bar Icons
Icon Description Icon Description
Notifications
Indicates a reminder of an upcoming calendar
event.
Notification that one or more instant messages
were received.
Notification that one or more e-mail/text
messages were received.
There are more notification icons than can be
displayed.
Connectivity
Connection is active. Connection is not active.
Synchronization is occurring. WLAN available.
WLAN in use.
Audio
All sounds are on. All sounds are off.
Battery
Battery is charging. Battery has a full charge.
Battery has a high charge. Battery has a medium charge.
Battery has a low charge. Battery has a very low charge.
Battery
Audio
Connectivity
Notifications
Battery
Clock
