5
-
4
MC9190-G
User
Guide
Rugged Cable Headset
RCH50
Rugged headset
RCH50 Adapter Cable
25-124387-01R
RCH50 adapter cable for standard 3-pole, 2.5mm
barrel jack used with MC9190-G.
UBC2000 Wall Mount Kit
KT-32665-01R
Use for mounting UBC2000 onto a wall.
Table
5-1
MC9190-G Accessories
Accessory
Part
Number
Description
93
95
