9.13.1 Setting the switching pulse for controlling the motor-drive unit
You can use the parameters Switching pulse type, Switching pulse time and
Switching pulse pause to adapt the device switching pulse to the require-
ments of the motor-drive unit controller.
1. Go to Settings > Parameters > Motor and control cabinet > Motor
control.
2. Select the desired parameter.
3. Set the parameter.
4. Press the Accept button to save the modified parameter.
Switching pulse type
You can use this parameter to toggle the switching pulse between a continu-
ous pulse or a time-controlled switching pulse.
Continuous pulse Selecting the "Continuous pulse" option causes the device to issue the
switching pulse in AVRAuto operating mode until the measured value is
back within the bandwidth. In AVRManual operating mode, the device is-
sues the switching pulse for as long as you press the or key.
If the device is operated as a follower in parallel operation in this case, then
the TAPCON® will issue the switching pulse until one of the following re-
quirements has been met:
▪ The set motor runtime has been reached
▪ The Motor running signal switches from state 1 to 0
▪ The tap position required by the master has been reached
A pause is enforced after every switching pulse before another switching
pulse is issued.
Time-controlled switching
pulse
Selecting the "Time-controlled switching pulse" option causes the device to
issue the switching pulse for a set duration. A pause is enforced after ev-
ery switching pulse before another switching pulse is issued.
If you use a motor-drive unit from Maschinenfabrik Reinhausen GmbH, you
need to select the "Time-controlled switching pulse" option.
