Q switching direction (optional)
You can use this parameter to set the switching direction for reactive power
regulation. You can use this to adjust the behavior of the device based on
how your on-load tap-changer and motor-drive unit are configured. You can
select the following options:
Setting Meaning
Standard The device issues a signal via the RAISE output to increase
the reactive power.
The device issues a signal via the LOWER output to reduce
the reactive power.
Swapped The device issues a signal via the LOWER output to increase
the reactive power.
The device issues a signal via the RAISE output to reduce the
reactive power.
Table43: Behavior
Switching direction monitoring
You can use this parameter to set the switching direction monitoring. This
function monitors whether a tap-change operation in the wrong direction has
been undertaken (e.g. due to a wiring mistake).
If a tap-change operation in the wrong direction is detected, the device is-
sues the event message Switching direction monitoring and blocks auto-
matic regulation. Automatic regulation is blocked until you acknowledge
[►Section 9.33.1, Page 311] the event.
Switching direction monitoring is not active if you control the motor-drive unit
with a continuous pulse [►Section 9.13.1, Page 170].
9.14 Drive overview
The overview display of the motor-drive unit shows you the following infor-
mation:
▪ Current tap position, including drag hands
▪ Display of tap-change indicator sections (SSE, optional)
▪ Operations counter
▪ Status messages
– Operating mode
– Switching blocking (optional)
– Motor protective switch
– Control cabinet door open/closed
▪ Ambient temperature (optional)
