6 Mounting
Maschinenfabrik Reinhausen GmbH 2020 636385142/08 EN ETOS
®
ED
6.2 Mounting drive shafts and bevel gear
The process of mounting the drive shafts and bevel gear is described in the
installation and commissioning instructions for the on-load tap-changer / de-
energized tap-changer.
6.3 Centering on-load tap-changer and motor-drive unit
WARNING
Danger of death or severe injury!
Danger of death or severe injury due to motor-drive unit starting up by acci-
dent and due to electric voltage!
Before starting any coupling work make sure that the motor protective
switch is tripped.
Carry out any adjustment work in manual mode only.
When manually operating the motor-drive unit only use the hand crank
provided for this purpose.
Note that the hand crank safety switch causes a 2-pole disconnection of
the motor circuit but that the control circuit is not interrupted.
NOTICE
Damage to property!
The on-load tap-changer will be damaged by incorrectly centering the mo-
tor-drive unit.
Do not perform more than 250 tap-change operations on the on-load tap-
changer. If more than 250 tap-change operations are performed, com-
pletely fill oil compartment with insulating oil and lubricate sliding surfaces
of contacts on selector and selector gear with insulating oil.
The following steps for centering the on-load tap-changer and motor-drive
unit do not apply to the DEETAP® DU or COMTAP® ARS devices. The
process for centering the motor-drive unit and DEETAP® DU or COMTAP®
ARS devices is described in the relevant operating instructions.
One on-load tap-change operation is represented by one rotation of the tap-
change indicator. This indicator is divided into 33 tap-change indicator sec-
tions, each of which corresponds to one hand crank revolution in the stan-
dard motor-drive unit design. The time of the switchover depends on the on-
load tap-changer / de-energized tap-changer type, but is always 2 tap-
change indicator sections upstream of the area marked in gray on the tap-
change indicator at the latest.
To center the on-load tap-changer and motor-drive unit, proceed as follows.
1. NOTICE! Move the on-load tap-changer / de-energized tap-changer and
the motor-drive unit into the adjustment position before commencing any
adjustment work. Ensure that the tap position indicators for the motor-
