9 Visualization
Maschinenfabrik Reinhausen GmbH 2020 3296385142/08 EN ETOS
®
ED
9.37.2 Configuration
You can use the web interface to configure the Ethernet switch. You can find
more information about the configuration using the online help in the web in-
terface.
Calling up the web interface
To access the web interface, follow the instructions outlined in the Commis-
sioning [►Section 9.37.1, Page 327] chapter.
Selecting the redundancy protocol
To select the redundancy protocol, proceed as follows:
1. Go to Redundancy.
2. Select the specific menu item for the redundancy protocol.
3. Change the configuration and select the On option in the Function group
field.
4. In the Basic settings > Load/Save menu, click on the Save button to per-
manently store the settings.
Deactivate the unused redundancy protocols by selecting the Off option in
the Function group field.
Resetting to factory settings
To reset the Ethernet switch to its factory default settings, proceed as fol-
lows:
1. Go to Basic settings > Load/Save and click on the Reset to factory de-
faults… button.
2. Reestablish the connection to the IP address of 192.168.1.1 if necessary.
3. Set the MR factory settings in accordance with the following table.
Menu Parameter MR factory setting
Redundancy Redundancy protocol PRP
Security > Pre-login
banner
Login banner MR-specific
Basic setting > Port
configuration
Ports 5+6 Deactivated
Table101: MR factory setting
