9 Visualization
Maschinenfabrik Reinhausen GmbH 2020 1476385142/08 EN ETOS
®
ED
2. Adjust the data points as required.
3. Press the Accept button to adopt the modified list of data points.
4. Restart the device to activate the modified list of data points.
9.8.8.6 Resetting the data point configuration to factory settings
If you want to reset the data point configuration to factory settings, proceed
as follows:
1. Go to Settings > Data point configuration.
2. Press the Reset button.
ð The message Reset appears.
3. Press the Yes button to reset the data point configuration to the factory
settings.
4. Restart the device to activate the modified list of data points.
9.8.8.7 Exporting and importing the data point configuration
You can export the data point configuration, e.g., to back it up or import it
into another device. You will find more information in the Import/Export Man-
ager [►Section 9.36, Page 324] section.
9.8.9 Display status of the SCADA connection
This display shows you the status of the connection to the control system.
The following information is displayed:
▪ Connected: The device has established a connection to the control sys-
tem.
▪ Rx: The device has received a message from the control system.
▪ Tx: The device has transmitted a message to the control system.
The display is not available for the Modbus ASCII, Modbus RTU, Modbus
TCP or DNP3 serial control systems.
