9 Visualization
Maschinenfabrik Reinhausen GmbH 2020188 6385142/08 ENETOS
®
ED
Desired
value
BCD input
100 80 40 20 10 8 4 2 1
76 V 0 0 1 1 1 0 1 1 0
77 V 0 0 1 1 1 0 1 1 1
78 V 0 0 1 1 1 1 0 0 0
79 V 0 0 1 1 1 1 0 0 1
80 V 0 1 0 0 0 0 0 0 0
81 V 0 1 0 0 0 0 0 0 1
82 V 0 1 0 0 0 0 0 1 0
83 V 0 1 0 0 0 0 0 1 1
84 V 0 1 0 0 0 0 1 0 0
85 V 0 1 0 0 0 0 1 0 1
86 V 0 1 0 0 0 0 1 1 0
87 V 0 1 0 0 0 0 1 1 1
88 V 0 1 0 0 0 1 0 0 0
89 V 0 1 0 0 0 1 0 0 1
90 V 0 1 0 0 1 0 0 0 0
91 V 0 1 0 0 1 0 0 0 1
92 V 0 1 0 0 1 0 0 1 0
93 V 0 1 0 0 1 0 0 1 1
94 V 0 1 0 0 1 0 1 0 0
95 V 0 1 0 0 1 0 1 0 1
96 V 0 1 0 0 1 0 1 1 0
97 V 0 1 0 0 1 0 1 1 1
98 V 0 1 0 0 1 1 0 0 0
99 V 0 1 0 0 1 1 0 0 1
100 V 1 0 0 0 0 0 0 0 0
101 V 1 0 0 0 0 0 0 0 1
102 V 1 0 0 0 0 0 0 1 0
103 V 1 0 0 0 0 0 0 1 1
104 V 1 0 0 0 0 0 1 0 0
105 V 1 0 0 0 0 0 1 0 1
106 V 1 0 0 0 0 0 1 1 0
107 V 1 0 0 0 0 0 1 1 1
108 V 1 0 0 0 0 1 0 0 0
109 V 1 0 0 0 0 1 0 0 1
110 V 1 0 0 0 1 0 0 0 0
