10 Fault elimination
Maschinenfabrik Reinhausen GmbH 2020 3576385142/08 EN ETOS
®
ED
Characteristics/details Cause Remedy
Ambient temperature limit value
▪ Event No. 1026, 1027, 1028 or
1029
Ambient temperature is greater
than the > limit value.
Check the measured value for plausibility.
This event will be reset automatically once the
measured value is lower than the limit value
again.
Ambient temperature is greater
than the >> limit value.
Ambient temperature is less than
the < limit value.
Check the measured value for plausibility.
This event will be reset automatically once the
measured value is greater than the limit value
again.
Ambient temperature is less than
the << limit value.
Configuration error Check the configuration of the analog input
[►Section 9.29, Page 292].
Check the limit value setting.
Wiring error Check wiring as per connection diagram.
▪ Sensor CT372, terminal X6.1:5/8
Sensor defective Replace sensor
Ambient temperature invalid
▪ Event No. 1001
Configuration error Check the configuration of the analog input
[►Section 9.29, Page 292].
Wiring error Check wiring as per connection diagram.
▪ Sensor CT372, terminal X6.1:5/8
Sensor defective Replace sensor
Sensor for ambient temperature
defective
▪ Event No. 1844
Sensor defective Replace sensor
Top-oil temperature limit value
▪ Event No. 1112, 1113, 1114 or
1115
Top-oil temperature is greater than
the > limit value.
Check the measured value for plausibility.
This event will be reset automatically once the
measured value is lower than the limit value
again.
Top-oil temperature is greater than
the >> limit value.
Top-oil temperature is less than
the < limit value.
Check the measured value for plausibility.
This event will be reset automatically once the
measured value is greater than the limit value
again.
Top-oil temperature is less than
the << limit value.
Configuration error Check the configuration of the analog input
[►Section 9.29, Page 292].
Check the limit value setting.
Wiring error Check wiring as per connection diagram.
▪ Sensor CT375, terminal X6.1:9-12
Sensor defective Replace sensor
Upper oil temperature invalid
▪ Event No. 1123
Configuration error Check the configuration of the analog input
[►Section 9.29, Page 292].
Wiring error Check wiring as per connection diagram.
▪ Sensor CT375, terminal X6.1:9-12
Sensor defective Replace sensor
