12 Removal
Maschinenfabrik Reinhausen GmbH 2020 3716385142/08 EN ETOS
®
ED
Figure262: Maximum permissible cable angle for the lifting-gear limit stop of the control cabinet
1. Remove the nuts for fastening the control cabinet.
2. Lift the control cabinet away from the transformer.
3. WARNING! Serious injuries due to the control cabinet tipping and
damage to the cable gland if the control cabinet is set down, transported
or stored upright. Only set down, transport and store the control cabinet
on its back.
