5 Packaging, transport and storage
Maschinenfabrik Reinhausen GmbH 2020 596385142/08 EN ETOS
®
ED
▪ WARNING! Serious injuries and damage to the control cabinet due to
falling load. Attach the lifting gear such that the cable angle is always less
than 45° in relation to the vertical.
Figure37: Maximum permissible cable angle for the lifting-gear limit stop of the control cabinet
▪ WARNING! Serious injuries due to the control cabinet tipping and
damage to the cable gland if the control cabinet is set down, transported
or stored upright. Only set down, transport and store the control cabinet
on its back.
▪ Only remove the control cabinet from the crane once it has been fully con-
nected to the transformer.
