6 Mounting
Maschinenfabrik Reinhausen GmbH 202066 6385142/08 ENETOS
®
ED
in the same direction (example: 8-2=6) to complete the tap-change opera-
tion. Then turn in the opposite direction until the pointer is in the mid-posi-
tion of the area marked in gray on the tap-change indicator.
Figure46: Completing the diverter switch operation
6. Turn the hand crank counter-clockwise until the diverter switch operation
begins.
Figure47: Turning the hand crank in the opposite direction
