Pierce Gas Delay
The Pierce Gas Delay function is used in conjunction with the capacitive cutting head to configure the length of
time in seconds before the pierce gas is applied to the cutting head.
1. Press Menu
to access the menu system.
2. Press X-axis Jog Arrows
until Params_2D is highlighted in blue.
3. Press Enter
to access the Params_2D sub-menu.
4. Press X-axis Jog Arrows
until Pierce Gas Delay is highlighted in blue.
5. Press Enter
to adjust the pierce gas delay.
6. Enter the Pierce Gas Delay using the number keypad (e.g., 0).
7. Press Enter
to record the Pierce Gas Delay and return to the Params_2D sub-menu.
Params_2D
Menu
