Innovation. Quality. Performance. Best in Industry. Worldwide.
Enter
Press Enter to accept functions, settings, and menu items as directed. The display may provide a question
mark “?” when processing certain functions. The operator can press Enter
to verify that the action should
take place.
Hot Keys Keypad
Find Home
The Find Home function allows the operator to return each axis to the machine home position in order to relocate
the homing targets. The head assembly will move to the right front of the table and index all X, Y, Z components
starting with the Z-axis.
1. Press Shift and Go Home to index the gantry, carriage, and Z assembly off of the limit switches after
one of the following actions has been completed:
a. The machine has just been turned on.
b. The machine has stalled or lost its position coordinates.
c. The machine has been stopped because the operator pushed in E-Stop.
2. Refer to the display as it will indicate when the system locates the targets for each axis. The head assembly will
be enabled when the Find Home function has been activated. Hot Keys
Keypad
Routers * Lasers * Plasma * WaterJets * Knife Cutters
www.MultiCam.com v. 11 10
