Pen Number
The Pen Number function is used to output a file to the machine with multiple tool path attributes in a manner
similar to using different tool numbers when creating a router program. The default settings are shown below:
* Pen 1—Cutting
* Pen 2—Engraving
* Pen 16—Rastering
1. Press Menu
to access the menu system.
2. Press X-axis Jog Arrows
until Params_2D is highlighted in blue.
3. Press Enter to access the Params_2D sub-menu.
4. Press X-axis Jog Arrows until Pen Number is highlighted in blue.
5. Press Enter
to change the pen number. MultiCam recommends that operators not adjust the default
settings without direction from a service technician. Params_2D
Menu
