Kerf Diameter
The Kerf Diameter function is used to establish the diameter of the beam while cutting.
1. Press Menu
to access the menu system.
2. Press X-axis Jog Arrows
until Params_2D is highlighted in blue.
3. Press Enter
to access the Params_2D sub-menu.
4. Press X-axis Jog Arrows
until Kerf Diameter is highlighted in blue.
5. Press Enter
to change the value.
6. Enter the kerf diameter using the number keypad (e.g., 0.000).
7. Press Enter
to record the Kerf Diameter and return to the Params_2D sub-menu.
Params_2D
Menu
