Innovation. Quality. Performance. Best in Industry. Worldwide.
Contrast
The Contrast function is used to adjust the contrast of the image when images are being rastered. The system
automatically defaults to 50, but the operator may change this value.
1. Press Menu
to access the menu system.
2. Press X-axis Jog Arrows
until Params_2D is highlighted in blue.
3. Press Enter
to access the Params_2D sub-menu.
4. Press X-axis Jog Arrows
until Contrast is highlighted in blue.
5. Press Enter
to change the contrast value. The cursor will be over the entry for the current contrast.
6. Enter the desired contrast using the number keypad (e.g., 50).
7. Press Enter to record the Contrast and return to the Params_2D sub-menu.
Params_2D
Menu
Routers * Lasers * Plasma * WaterJets * Knife Cutters
www.MultiCam.com v. 11 10
