c. Enter 1 for Home 1 and press Enter to record the Soft Home.
d. Press Jog Arrows to position the center of the head assembly where the second Soft
Home location should be set.
e. Press Shift and Soft Homes .
f. Enter 2 for Home 2 and press Enter to record the second Soft Home.
4. Press DNC .
5. Press X-axis Jog Arrows until the blinking cursor is over the appropriate job file.
6. Press Enter to access the job file.
7. Push button 1 or 2 on the op station to move the spindle to Soft Home 1 or 2.
8. Press Start
to begin the file.
9. Press the other button on the op station to run the same job at the other Soft Home location after the first job
file has been completed. Operators should make sure the material has been properly loaded at the other location
before beginning the job file at that location. Advanced
