2.3 Roller designation
2.3.1 Identification plate
An identification plate is affixed to the roller for identification. The identification plate
is attached to the rear part of the chassis below the steering column.
Fig. 2-2 Data on the identification plate
NOTE When ordering spare parts you must indicate the serial number (S/N) of the rol-
ler.
1 Roller designation
2 Homologation number
3 Name and address of the manufacturer
4 Vehicle Identification Number (VIN)
5 Roller model
6 Year of manufacture
7 Serial number
8 Fuel engine output at
9 Speed of fuel motor (rpm )
10 CECE total weight
11 Axle load, front
12 Axle load, rear
13 Number stamped in chassis
1
2
5
6
7
8
11
4
9
3
12
10
13
