PAGE 14 — RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL — REV. #0 (04/28/15)
Safety information 25
1230047 | 21.06.2013
3.2.1 Shear points
● When closing the hood ensure that no objects are situated between the hood and
the chassis.
● Take care that nothing is jammed in the joint plates when rotating the roller drums.
● Do not put hands between the roller drum and support during operation.
Fig. 3-1 Tipping hazard
Construction site conditions can have a negative effect on stability and the tipping
angle.
DANGER
Danger to life through tipping or slipping of the roller! The ed-
ges of filled areas may give way!
• Only travel directly up or down slopes.
• Do not drive across slopes.
• Keep your distance to embankments and edges!
• Do not drive at an angle into or out of the trench.
• Park the roller on slopes only in such a way that it cannot over-
turn.
• Use the roller on slopes only in such a way that it cannot over-
turn.
• The roller drums have very poor adhesion on snow and ice. Dri-
ving or working on a slope in snow or ice is prohibited.
• Damp a
nd loose surfaces reduce the traction of the machine on
upward and downward grades considerably. Adapt the speed
of the machine to the terrain when driving on grades.
• The nature of the ground and weather conditions can negati-
vely affect the climbing ability of the machine.
Never drive on slopes that are steeper than the maximum clim-
bing ability of the machine.
SAFETY INFORMATION
