PAGE 48 — RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL — REV. #0 (04/28/15)
68 Rammax 1575
1230047 | 21.06.2013
9.6.2 Right side of the engine
Fig. 9-3 Right side of the engine
1 Engine oil filler neck
2 Alternator
3 Fuel pump
4 Coolant level display
5 Flow divider
6 Nozzle block
7 Water separator
WARNING
Risk of burning and injury when handling parts in the engine
compartment!
• Switch the diesel engine off when performing any inspection
work. The locking brake is active when the diesel engine is
switched off.
MAINTENANCE
