RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL — REV. #0 (04/28/15) — PAGE 33
50 Rammax 1575
1230047 | 21.06.2013
7.1 Protection against vandalism
Always fold the vandalism protection cover upward before start-up of the roller.
The vandalism protection cover protects the display unit and the infrared sensor
from:
● the effects of weathering
● vandalism
● alterations by third parties
If you wish to secure the display unit and the infrared sensor from unauthorized
access by third parties, you can install a padlock on the loop provided for this pur-
pose.
Commercially available padlocks can be obtained in any building supplies store.
Fig. 7-1 Vandalism protection cover opened/closed
7.2 Start the engine
7.2.1 Starting the engine using the ignition switch
7.2.2 Starting the engine using the infrared transmitter
1 Turn the ignition key clockwise to position I.
2 Hold the switch on the infrared sensor in the start position.
2.1 Preglow for a max. of 6sec.
3 Release the switch.
0 Off
All electrical loads are off.
I Ignition on
All electrical consumers can be switched on.
II Pre-heating
III Start
