PAGE 80 — RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL — REV. #0 (04/28/15)
102 Rammax 1575
1230047 | 21.06.2013
Turn the engine
over using the
starter
1 Turn the engine over using the starter for 1-2 minutes.
After a few revolutions, the oil which has gathered in the combustion chambers
should have been pressed out through the openings for the glow plugs.
Repeat the procedure after about 5 minutes. It is essential to be sure that no more
oil is present in the combustion chambers!
2 Reinstall the glow plugs (AF size12, torque, 18Nm).
Fig. 10-20 Glow plugs
3 Reconnect the contact connectors and cables to the glow plugs (AF size8, tor-
que, 1.5 Nm).
Fig. 10-21 Connection cable
4 Install the valve cover.
5 Install the electrical steel.
Turn the engine
over with the igni-
tion key
1 Turn the ignition key clockwise to position III.
1.1 The engine must turn over.
WARNING
Danger of burns due to ejected oil!
Eye injury, burns
• Wear safety goggles
1
23
4
1
23
4
REPAIR
