PAGE 38 — RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL — REV. #0 (04/28/15)
Operation 55
1230047 | 21.06.2013
All of the distance values indicated are measured between the front or back infrared
sensor and the infrared transmitter.
The table below shows the approximate distance values for this feature.
Tab. 7-1 Distance values for close proximity and distant shutdown
NOTE The distance values can vary in dependence on weather conditions. If the ma-
ximum range is exceeded in infrared operation/cable operation, the diesel en-
gine continues to idle, but the functions are interrupted. Reduce the distance
to the machine in order to resume control of it.
7.5 Turning off the engine
1 Move the switch on the infrared transmitter to “STOP”.
2 Turn the ignition key to the “0” position.
Cable operation IR operation
Close proximity shutdown approx. 6.5 ft (2 m) approx. 6.5 ft (2 m)
Distant shutdown approx. 13 ft (4 m) approx. 65 ft (20 m)
CAUTION
As long as the “Start-Stop” rocker switch is placed in the
“neutral” position, the transmitter remains operational.
• Always switch off the transmitter during work breaks and after
completing work by moving the rocker switch to the “Stop” po-
sition.
OPERATION
