Fig. 4-3 Cockpit overview
Fig. 4-4 Overview of interior of rear chassis
1 Infrared transmitter
2 Storage area for spiral cable
3 Display unit
4 Ignition switch
5 Fuses
1 Oil cooler
2 Fuel tank
3 Hydraulic tank
4 Battery
5 Controller (machine controller)
1
3
4
2
5
6 Connector for spiral cable to infrared sensor (back area)
