RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL — REV. #0 (04/28/15) — PAGE 71
Repair 93
1230047 | 21.06.2013
NOTE The battery poles and terminals must be clean. If they are coated with a (whi-
tish or greenish) sulfur crust they must be cleaned.
10.1.2 Starting with another battery (jumpering)
1 Connect the red cable to the (+) terminals of both batteries.
2 Connect one end of the green or black cable to the (-) terminals of both batte-
ries.
3 Actuate the starter. Allow the engine to run.
4 Wait until the engine is idling smoothly and then disconnect the cables.
4.1 Begin with the (-) terminal.
NOTE The battery poles and terminals must be clean. If they are coated with a (whi-
tish or greenish) sulfur crust they must be removed and cleaned.
10.1.3 Charging the battery using a battery charger
1 Disconnect the battery.
2 Connect the battery charger.
2.1 Observe the battery charger manufacturer’s manual.
3 Start with the (+) terminal when reconnecting the battery.
NOTE The battery poles and terminals must be clean. If they are coated with a (whi-
tish or greenish) sulfur crust they must be removed and cleaned.
10.1.4 Long-term storage
Remove the negative battery cable from the battery if a standstill period of more than
two weeks is expected.
10.2 Fuses
DANGER
There is danger to life if the roller does not stop in hazardous
situations!
• Fuses and safety switches must never be shorted.
REPAIR
