9.15 Consumables
Tab. 9-3 Consumables
NOTE The screws can loosen due to the vibration of the roller!
• Unless otherwise specified, secure all screws with blue thread-lock.
9.16 Tightening torques
The values below apply:
● Unless otherwise specified in the operating manual or in the workshop manual
● To female steel threads
9.16.1 Screws
Tab. 9-4 Tightening torque: Hex screws/bolts (including tapping screws) and hexagon-socket-head
screws
Designation Brand Quantity Art.no.
Engine oil Motorex Focus CF SAE 10W/40 1l 1242375
Grease Motorex Moly 218 400g 1111368
Grease Motorex 174 0.85kg 1144019
Grease Blaser Foodgrease SPM00 0.38kg 1094392
Blue adhesive Ergo 4052 50ml 1-907977
Red adhesive Ergo 4100 50ml 1-907978
Paint spray RAL dark gray 400ml 1202234
Paint spray RAL 1016 Sulfur yellow 400ml 1-922700
Paint spray RAL 6033 Mint turquoise 400ml 1-922701
Sealant Ergo 4207 250g 1-923054
AF
size
hex
AF
size
Allen
Screw
diameter
Steel quality
Tightening torque in
Nm
7 3 M4 8.8 3
8 4 M5 8.8 6
10 5 M6 8.8 10
13 6 M8 8.8 25
13 6 M8 10.9 36
15 M10x1.25 10.9 90
