MULTIQUIP Rammax Series - Legend for Rammax 1575 Hydraulic Circuit Diagram

PAGE 94 — RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL — REV. #0 (04/28/15)
Appendix 123
1230047 | 21.06.2013
14.2.1 Legend for Rammax 1575 hydraulic circuit diagram
Element Description
1 Drive pump
2 Vibro-steering pump
3 Drive motor, rear left
4 Drive motor, rear right
5 Front left drive motor
6 Front right drive motor
7 Left steering cylinder
8 Right steering cylinder
9 Vibro steering/brake valve
10 Vibro motor, front
11 Vibro motor, rear
12 Oil cooler
13 Return-line suction filter
14 Hydraulic oil tank
15 Filler, ventilation filter
16 Diesel tank
17 Nozzle block
APPENDIX
