RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL — REV. #0 (04/28/15) — PAGE 73
Repair 95
1230047 | 21.06.2013
10.2.2 Cockpit fuses
The fuses are located under the cowling in the cockpit
Tab. 10-2 Cockpit fuses
Fig. 10-4 Cockpit fuses
NOTE Faulty installation can cause short circuiting or a cable fire.
• When replacing fuses, do not mix them up.
10.3 Gas strut
Gas struts are maintenance-free! They require no maintenance such as lubrication.
They are designed for the respective requirements and work trouble-free for many
years.
10.3.1 Replacing gas struts
removal 1 Use a screwdriver to lift the clips.
2 Pull the gas strut away from the ball joint.
Item Fuse No. Power Fuse-protected circuit
1 F11 10 A Controller, power supply
2 F12 25 A Controller, outputs
3 F13 10 A Display unit, shutdown bar
4 F14 25 A Hydraulic oil cooler
WARNING
Risk of accident through hood falling down!
• Secure the hood before you replace the gas struts.
○ Support the hood with a rod.
○ Attach the hood to a crane by the handle.
!
REPAIR
