PAGE 30 — RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL — REV. #0 (04/28/15)
44 Rammax 1575
1230047 | 21.06.2013
5.2.4 Handling
Sticker
The infrared transmitter is located in the black lower part of the housing. It contains
the following transmission elements:
● The solar cells
● The infrared diodes for data transmission and measuring the safety distance.
● Before startup, clean the transmission elements.
● Before startup, be sure that the solar cells in the lower part of the housing are not
covered over.
● Keep the solar cells clean during operation.
Wear the infrared transmitter correctly
1 Pay attention to correct positioning.
1.1 The cable connector must face forwards or be oriented according to the
sticker on the transmitter. The infrared transmitter may rest on the sto-
mach of the operator.
1.2 Adjust the strap for the correct length to ensure optimal wearing com-
fort.
2 Pay attention to correct operation.
2.1 Only hold the housing by the upper part; see the warning information.
CAUTION
Accident hazard due to covered over lower part of the
housing!
• Before and during operation with the infrared transmitter, make
sure that the entire lower part of the housing remains comple-
tely uncovered for the entire time of operation.
• In particular, the operator’s hand must not cover the lower part
of the housing even partially.
OPERATING AND DISPLAY ELEMENTS
