RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL — REV. #0 (04/28/15) — PAGE 87
Transport 111
1230047 | 21.06.2013
Fig. 12-4 Lashing the roller/front view
12.2.3 Center of gravity
The center of gravity relevant to transport is located 460mm from the floor and
approx. in the center of the roller, depending on the fill level of the diesel or water
tanks.
Fig. 12-5 Roller's center of gravity
CAUTION
Risk of accident through blocked steering!
• Open the joint protection before starting the roller.
