RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL — REV. #0 (04/28/15) — PAGE 91
Appendix 119
1230047 | 21.06.2013
14.1.1 Legend for Rammax 1575 wiring diagram
Element Description
F11 Fuse, controller, supply
F12 Fuse, controller, outputs
F13 Fuse, display unit, shutdown bar
F14 Fuse, hydraulic oil cooler
F21 Fuse, pull-in solenoid
F22 Fuse, diesel pump, alternator
F23 Fuse, operating speed
F24 Fuse, pre-heating coil
F25 Fuse, “2nd solenoid”
G1 Alternator
G2 Battery
K1 Relay, ignition
K2 Relay, starting interlock
K3 Timer relay
K4 Relay, pull-in solenoid
K5 Relay, operating speed
K6 Relay, pre-heating coil
K7 Relay, hydraulic oil cooler
K11 Relay, “solenoid driver”
M1 Starter motor
M2 Diesel pump
M3 Hydraulic oil cooler
N1 Machine controller
N2 Display unit
N3 Infrared transmitter
P1 Front infrared transmitter
P2 Rear infrared transmitter
R1 Pre-heating coil
S1 Switch, ignition switch
S21 Sensor, engine oil pressure
S22 Sensor, coolant temperature
S24 Sensor, shutdown bar
S25 Sensor, hydraulic oil temperature
Y1 Magnet, pull-in/holding solenoid
