PAGE 32 — RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL — REV. #0 (04/28/15)
48 Rammax 1575
1230047 | 21.06.2013
6.1 Commissioning
NOTE Familiarize yourself with the manual before commissioning.
6.1.1 Inspection before commissioning
In order to begin operating the roller (driving), the following conditions must be fulfil-
led:
The following must be checked:
● The function of all safety devices
● Whether the transport restraint has been removed
● Whether the shutdown bar has been released
● All screw connections for tightness
● Fuel tank and pipes for leaks
● Machine and engine for damage
● Function of the controls
● Function of the steering
● Hydraulic system for leaks
● IR transmitter battery status (LED must be lit).
● Pair infrared transmitter with the machine controller (see below).
● Electronic ballast interference (an external influence from fluorescent tubes)
NOTE The infrared transmitter does not work and no LEDs are lit.
• Connect the transmitter to the machine via the spiral cable. The battery will
be charged!
6.1.2 Automatic pairing of infrared transmitter and machine controller
In order to operate the machine using the infrared transmitter, they must first perform
a mutual address assignment. This is only necessary if a new infrared transmitter
must be registered on the machine.
1 Connect the cable to the transmitter.
2 Turn the ignition key to position I.
3 After approx. 3 seconds, the cable can be removed.
The cable is not required for infrared operation.
NOTE Pairing is required in order to operate the machine with a new infrared trans-
mitter. Pairing ensures that only one machine can be operated with one trans-
mitter.
The green LED and the red LED blink during pairing
COMMISSIONING
