PAGE 6 — RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL — REV. #0 (04/28/15)
It is essential that you read chapter 3 Safety information carefully before
commissioning and carrying out maintenance work.
Observing the "safety instructions" in particular increases the reliability of the roller in
operation and its service life. This reduces repair costs and down time.
1.2.1 Orientation on the roller
When describing the components of the roller, we inform you of their position on the
roller. We adhere to the orientation below when doing so.
Fig. 1-1 Rammax 1575 orientation
We view the roller from the position of the driver standing behind the roller looking in
the direction of travel.
1.2.2 Warnings
Please observe the meaning of the following warnings:
● DANGER represents an immediate hazard leading to severe bodily injury or
death.
● WARNING represents a possibly hazardous situation which could lead to se-
vere bodily injury or to death.
Rear
Top
Bottom
Left
Right
Front
DANGER
WARNING
!
!
GENERAL
