RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL — REV. #0 (04/28/15) — PAGE 23
36 Rammax 1575
1230047 | 21.06.2013
Fig. 4-5 Front bottom view
1 Engine oil drain plug
STRUCTURE AND FUNCTION
