PAGE 18 — RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL — REV. #0 (04/28/15)
Safety information 29
1230047 | 21.06.2013
3.4.2 Notice stickers
Tab. 3-3 Notice stickers on board
Location on roller: Inner cowling cover.
Designation: If the roller has overturned, do not start the machine.
Explanation: Avoid oil shock.
Location on roller: Outer cowling cover.
Requirement: Wear ear protectors!
Explanation: Wear ear protectors in accordance with nati-
onal accident prevention regulations when working at hig-
her noise levels.
Warning stickers Meaning
Notice stickers Meaning
Location on roller: Chassis rear
Designation: Guaranteed sound power level.
Explanation: Indicates the overall noise level produced by
the roller.
Location on roller: On the hydraulic oil tank
Designation: Hydraulic oil
Explanation: Please only use hydraulic oil indicated
SAFETY INFORMATION
