FP0 Hardware A.1 System Registers
A-5Matsushita Electric Works (Europe) AG
C32 series
Timer Non-hold type: All points
Counter Non-hold type: From the set value to C127
Hold type: 16 points (elapsed values)
C128 to C143
Internal relay Non-hold type: 880 points (R0 to R54F)
55 words (WR0 to WR54)
Hold type: 128 points (R550 to R62F)
8 words (WR55 to WR62)
Data register Non-hold type: 6112 words (DT0 to DT6111)
Hold type: 32 words (DT6112 to DT6143)
Note
For more information on performance specifications, also for the
T32CP unit, see page 2-8.
