Setting Up The Networking Feature
IP Networking
Networking â—† 19
Programming
Also refer to the Numbering Plan (page 32) feature for additional
required programming.
âž»
10-12-01 : NTCPU Network Setup - IP Address
Select the IP address of the NTCPU (default: 172.16.0.10). A static IP address is required by
the NTCPU. Each Aspire system in the network must have a unique IP address. The system
must be reset in order for the change to take effect.
âž» 10-12-02 : NTCPU Network Setup - Subnet Mask
Select the Subnet Mask to be used by the IP server (default: 255.255.0.0).
Example:
âž» 10-20-01 : LAN Setup for External Equipment - TCP Port
DeÞne the TCP port number for communicating to external equipment. The port number
deÞned should be the same in each networked system.
Item
No.
Item Input Data Default Conditions
01 NTCPU
IP Address
1.0.0.1 - 126.255.255.254
128.1.0.1 -191.254.255.254
192.0.1.1 - 223.255.254.254
172.16.0.10
02 NTCPU
Subnet
Mask
128.0.0.0
240.0.0.0
254.0.0.0
255.192.0.0
255.252.0.0
255.255.128.0
255.255.248.0
255.255.255.0
255.255.255.224
255.255.255.252
192.0.0.0
248.0.0.0
255.0.0.0
255.224.0.0
255.254.0.0
255.255.192.0
255.255.252.0
255.255.255.128
255.255.255.240
255.255.255.254
224.0.0.0
252.0.0.0
255.128.0.0
255.248.0.0
255.255.0.0
255.255.224.0
255.255.254.0
255.255.255.192
255.255.255.248
255.255.255.255
255.255.0.0 The setting of Subnet-
Mask is mistaken when
all Host Address are 0.
If the network section
is:
0,
127
128.0
191.255
192.0.0
223.255.255
The setting of Subnet-
Mask is mistaken.
System – A System – B
IP Address: 172.16.0.10 IP Address: 172.16.0.11
Subnet Mask: 255.255.0.0 Subnet Mask: 255.255.0.0
Type of external equipment 1- CTI Server
2- ACD MIS
3- - Reserve -
4- Network Listener
5- SMDR
6- DIM Access
To Next Page
