CHAPTER 3 SYSTEM DATA PROGRAMMING
– 200 – NWA-008853-001 Rev.3.0
97ch3003.fm
DESCRIPTION DATA
Assign the attribute data, depending on the
port (Port 0-3) connected to the SMDR termi-
nal. (For the details of commands, refer to the
Command Manual.)
(1)
(2)
See the following table.
See the following table.
NOTE: For the Port 1 and Port 3, data speed 9600 bps cannot be set.
Assign the Charging Station Class number to
each station number.
(1)
(2)
X-XXXX: Station No.
00-15: Station Class No.
B
CMD001
AP00 INITIAL
FIRST DATA (1)
MEANING
SECOND
DATA
(2)
MEANING
PORT
0
PORT
1
PORT
2
PORT
3
20 24 28 32 Data Speed 2/3/4/5 1200 bps/2400 bps/4800
bps/9600 bps NOTE
21 25 29 33 Stop Bit Length 0/1/2 1 bit/1.5 bits/2 bits
22 26 30 34 Data Length 0/1 7 bits/8 bits
23 27 31 35 Parity 0/1/2 None Parity/Even Parity/
Odd Parity
80 100 120 140 Equipment Type 4/5 Computer 0/Computer 1
81 101 121 141 Priority for Data Processing 0 1st
82 102 122 142 Message Format 3 NEAX 2400 IMS Format
84 104 124 144 Protocol 1 Free Wheel
85 105 125 145 Station Address (SA) 48 0
86 106 126 146 Unit Address (UA) 33 !
CMD015
C
CENTRALIZED BILLING-CCIS
To Next Page
