NETGEAR D7000 User Manual

DescriptionField
Select LLC-BASED or VC-BASED, as indicated by your ISP.
The multiplexing method can either be virtual circuit (VC) based or logical link control
(LLC) based.
This setting does not apply to the IPTV interface.Note
Multiplexing Method
Enter a number between 0 and 255 for the virtual circuit number for the virtual path
identifier (VPI), as indicated by your ISP.
If your ISP did not provide you with a VPI setting, leave the default setting (8). The
VPI might be required not only for a VC-based connection but also for an LLC-based
connection.
This setting does not apply to the IPTV interface.Note
VPI
Enter a number between 32 and 65535 for the virtual circuit number for the virtual
channel identifier (VCI), as indicated by your ISP.
If your ISP did not provide you with a VCI setting, leave the default setting (35).The
VCI might be required not only for a VC-based connection but also for an LLC-based
connection.
This setting does not apply to the IPTV interface.Note
VCI
Select the Use VLANID check box and enter the VLAN ID, as indicated by your
ISP.
A VLAN ID might be required if you subscribe to both Internet service and IPTV
service. If your ISP did not provide you with a VLAN ID, leave the Use VLANID
check box cleared, which is the default setting.
Use VLANID
If your ISP provided you with a VLAN ID and a priority value, enter the priority value,
which is a number from 0 to 7.
You can enter a priority value only in combination with a VLAN ID. If your ISP did
not provide you with a priority value, leave the default setting (0).
Priority (0 ~ 7)
This setting is an option that applies to the IPTV interface only.
For information about configuring bridge mode, see Enable Bridge Mode for IPTV
Devices on page 202.
Bridge Mode
Manage the Internet Settings Manually
57
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000

NETGEAR D7000 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Modulation	PSK
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
Memory card slot(s)	No
Ethernet LAN (RJ-45) ports	5
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
DSL specification	VDSL, VDSL2, ADSL, ADSL2, ADSL2+
Web-based management	-
Firewall security	SPI, NAT
Security algorithms	WPA, WPA2-PSK, WPS
Product type	Tabletop router
Product color	Black
Housing material	Plastic
Flash memory	128 MB
Internal memory	256 MB
Processor cores	2
Processor frequency	1000 MHz
Windows operating systems supported	Windows 2000, Windows 7, Windows 8, Windows Vista, Windows XP
Cables included	LAN (RJ-45), Phone (RJ-11)
Supported network protocols	IPv6
Power source type	AC
Package type	Box

Weight and Dimensions

Depth	185 mm
Width	285 mm
Height	50 mm
Weight	750 g
